Disposable pulse cleaning device

Disposable pulse cleaning device

Product Summary：

The disposable pulse irrigation system produced by our company is a disposable irrigation system that provides pulse cleaning and suction. It is suitable for wound debridement, soft tissue debridement and surgical site cleaning.

Instructions
  1. Tear open the packaging dialysis paper and take the product out of the box;
  2. Insert the selected nozzle into the corresponding hole of the host, and hear a "pop", which means it has been connected in place;
  3. Connect one end of the sewage pipe provided by the hospital to the sewage pipe interface of the gun body, and one end to the vacuum suction pump;
  4. Insert the injection head connecting tube on the battery box into the bottom of the cleaning solution bag;
  5. The switch position is slow when pressed lightly, and fast when pressed heavily.Sliding the switch lock down can work in fast or slow gear for a long time;
  6. Use the flow control card to turn on or off the cleaning fluid
  7. When in use, the operator holds the host and the button switch.
  8. Note: After installation, check whether the battery can be used and the pipeline is sealed. This product is a sterile product. When the equipment is put into use, the equipment must be kept clean and not contacted by toxic or bacterial objects.
Features
  • Disposable,sterile disinfection porducts.
  • The porduct is light and portable, and can be used for outdoor emergency debridement;
  • Excellent dynamic performance, adjustable pulse pressure, suitable for all kinds of surgical debridement

Specifications
Model Structure and composition
FWS-WJ-001 It is composed of main engine (including power system and internal battery), flushing system pipeline and suction system pipeline.
FWS-WJ-001A It is composed of main engine (including power system and internal battery), flushing system pipeline and suction system pipeline.
Scope of application
  1. Orthopedic joint replacement, internal fixation of various fractures;
  2. Emergency trauma debridement;
  3. Intraoperative flushing during tumor surgery;
  4. General surgery, obstetrics and gynecology, cardiothoracic surgery, urology surgery;
  5. Dressing change and debridement in burn department;
  6. Cooperate with various endoscopes for intraoperative irrigation.
